Spectrophotometer UV5

UV-vis spectroscopy, fast and compact

The versatile benchtop UV/Vis spectrophotometer features translucent liquid, solid, and film analysis. Its reliable performance and flexible accessories and software make it the perfect solution for any lab looking to improve efficiency and accuracy.

 Options Cuvette changer, Handheld barcode scanner, Printer USB-P25,FillPal Mini pump, LinSet, Immersion, LabX PC software, CertiRef
Dimensions (Width) 208 mm (8.19 in)
Dimensions (Height) 228 mm (8.98 in)
Application Water, Colour, Scan, Quant
Compatibility with LabX Software Yes
Connectivity USB Interface Yes
Cuvette Changer Yes
Dimensions (Depth) 255 mm (10.04 in)
Display 7-inch QVGA Color TFT touch sensitive screen
Displayed Resolution 800×400
Languages English,Italian,French,Russian,Portuguese,Chinese,German,Spanish,Japanese
Light Source Xenon Flash Lamp
Max. number of methods 50
Minimal Scan time 1 s
Optics Array
Path length 16 mm,20 mm,50 mm,30 mm,40 mm,1 inch,10 mm
Pharmacopeia Compliant No
Photometric accuracy (K2Cr2O7) ±0.005 A
Product Line UV/VIS Excellence
Resolution (Toluene in hexane) >1.5
Shortcuts per user 12
Stray light (KCl, 198nm) >2
User Identification Yes
Wavelength accuracy ±0.9 nm
Wavelength Range 190 nm – 1,100 nm
Weight Including Terminal 6.4 kg
Product Family UV/VIS Excellence
  • Fixed Wavelength, Scan and Quant
  • Colour Measurement
  • Water Testing
  • Automatic Sampling and Cleaning
  • Automated Cuvette Changing
  • InMotion Autosampler
  • LabX UV/VIS Software
  • Direct Measurement and Methods
  • Efficient Accessories
  • Smart Result Management

Additional information

Brand

Product Code

30254725

Model

UV5
