| Measurement range Brix | 0-100 % w/w |
| Accuracy Brix | 0.014 % w/w |
| Measurement Scales | Refractive Index, Sugar (Brix and more), Acid/Base, Chemical, Freezing Point, Salt, Others Up to 30 user-defined concentration tables (can be entered as tables or formulas). |
| Weight | 4.8 kg |
| Minimum sample volume | 0.50 mL (0.5 mL) |
| Connectivity | 3 × USB host (printer, memory stick, barcode reader, hub, keyboard, mouse) CAN (Multiple LevelSens) Ethernet (Network and PC Software) HDMI (Terminal) RS232 (Automation units) USB client (PC Software) |
| Measurement Range nD | 1.32000 – 1.58000 |
| Accuracy nD (±) | 0.00002 |
| Temperature Control Range | 5 °C – 75 °C |
| Built-in Measurement Scales | Brix / Sugar tables, Chemicals, acids, bases and freezing point tables Others Refractive Index |
| Product Type | Benchtop refractometer |
| Dimensions (HxWxD) | 193 mm x 208 mm x 226 mm |
| Display / User interface | 7″ display with color touchscreen |
| PC Software | LabX Express and Server |
| Funnel for Easy Sampling | No |
| Password Protection | Yes |
| Languages | Chinese, English, French, German, Italian, Korean, Polish, Portuguese, Russian, Spanish |
| Repeatability nD (±) | 1e-005 |
| Standard compliance | www.mt.com/dere-norms |
| User Management | Yes |
| LIMS connectivity | Yes |
| Temperature control accuracy (±) | 0.03 °C |
| Dimensions (Width x Height x Depth) | 226 x 193 x 208 mm |
| Compliance / Data Security | 21 CFR part 11 / EU Annex 11 (requires LabX software) Audit Trail (requires LabX software) Data integrity (requires LabX software) |
| Color-coded result identification | Yes |
| On-screen help texts | Yes |
| Barcode reader connectivity | Yes |
