| Number of heating points | 1 |
| Heat output [W] | 1000 |
| Heating temperature range [°C] | 50 – 500 |
| Heat control | Turning knob |
| Connection for ext. temperature sensor | ETS-D5 |
| Volume max. [l] | 10 |
| Heating rate heating plate [K/min] | 5 |
| Set-up plate material | Ceramic |
| Set-up plate dimensions [mm] | 180 x 180 |
| Dimensions (W x H x D) [mm] | 220 x 105 x 330 |
| Weight [kg] | 5 |
| Permissible ambient temperature [°C] | 5 – 40 |
| Permissible relative humidity [%] | 80 |
| Protection class according to DIN EN 60529 | IP 21 |
| Voltage [V] | 230 |
| Frequency [Hz] | 50/60 |
| Power input [W] | 1005 |
