| Weight | 37kg (approx.) |
| Dimensions (DxWxH) | 535mm X 515mm X 450mm |
| Column Oven | |
| Size | H 290 mm x W 280mm x D160mm |
| Volume | 13.8Ltrs |
| Temperature | 5°C above the ambient temperature to 400°C |
| Ramp Rate | 1°C & 70°C per minute |
| No. of Ramps | 10 |
| Cooling Rate | 250°C to 50°C within approx. 5 minutes at 25°C room temp. |
| Temperature Gradient | 2°C max (on 200 mm dia circumference,40mm from the sensor) |
| Temperature Accuracy | + 1 % of set value from 50°c to 400°c |
| Heated Zones | 3/5 Independent Heated Zones up to 400°C for individual control of Injectors, detector, oven |
| Pneumatics | · Metal diaphragms regulators for Carrier gas, fixed flow restrictors for Hydrogen, Air and Make-up gas. Pressure switch provided to cut heating of oven, injector, FID power in the event of carrier gas flow depletion.
· Differential Flow Controllers for carrier gas for Packed Column Injectors: Pressure range O to 2 kg/cm2 Constant Pressure |
| Injection System | · Single/dual Split/split-less (capillary column) injector or single/dual packed injection port
· Temperature range settable up to 400°C. in the steps of 1°C |
| Display | 80 Characters (20 X 4 lines) LCD |
| Power Requirement | 230V Ac ± 10V Ac |
| Detector | · High sensitivity flame ionization detector with auto flame ignition, Temperature range settable up to 400°C. in the step of 1 °C
· Dynamic range 107 · Minimum Detection Level equivalent 3pg C/sec of Dodecane · Optional detectors: TCD, ECD, NPD |
